Bomba de seringa multi canal

Name: Bomba de seringa multi canal
Brand: Nanjing Runze Fluid Control Equipment Co., LTD.

Bomba de seringa multi-canal é umBomba de seringa de precisãoEspecialmente projetado para manuseio de líquidos de alta precisão com uma pequena pegada aplicada em espaços limitados. O vidro de borosilicato de caminho de fluido, PCTFE, safira é viável para produtos químicos corrosivos fortes em uma ampla faixa de aplicação. Está disponível para selecionar de uma variedade de volumes de seringa e configurações de válvula.

Enviar Correio

Video of Multi Channel Syringe Pump

Model Numbers of Multi Channel Syringe Pump

Smart SY-01B syringe pump is the newest member in the series of micro-syringe pumps self-developed by Runze Fluid, which can handling fluids from microliters to milliliters with extraordinary accuracy and precision. Accommodates distribution valves and syringe in a variety of configurations. Transfers liquid in high precision which can meet most users' requirements. Can be used in series with multiple pumps. The excellent performance of Smart SY-01B syringe pump provides a guarantee on the R & D and application for users. efficiency maintenance-free stepper motor drive system. Address up to 24 pumps individually via RS485 or CAN Communication.

Multi Channel Syringe Pump

Specification of Multi Channel Syringe Pump

Accuracy	≤1%@100% stroke
Precision (Repeatability)	0.3%~0.5%@100% stroke
Rated stroke (control steps)	30mm(12000 steps standard mode; 96000 steps micro-step mode)
Maximum speed	450rpm
Linear speed	0.0067mm/s ~ 15mm/s(media: water ; 1 rated stroke=one time)
Running time (per rated stroke)	2s-4500s(media: water ; 1 rated stroke=one time)
Resolution	0.0025mm (per step)
ILS Syringe	25μl, 50μl, 125μl, 250μl. 500μl, 1.25ml, 2.5ml, 5ml
Valve Model(available)	M01、M02、M03、M04、M05、M06、M10、M12
Wetted material	Borosilicate glass, PTFE, Sapphire, PCTFE
Max. Pressure Rating	0.7Mpa
Actuator	Trapezoidal screw (Lead 1mm/2mm)
Connection	1/4-28UNF
Baud rate	RS232/RS485: 9600bps, 38400bps
Communication addres	Up to 15 individual addresses can be provided
Firmware	Programmable acceleration/deceleration, termination of movement, programmable piston speed, diagnostic query error, programmable clearance compensation, absolute position or relative position, change speed on the fly, programmable Non-Volatile Memory
Power supply	DC24V/3A
Operating temperature	5℃~55℃
Operating humidity	<80% relative humidity, non-condensing
Dimension (LWH)	45143.3127mm
Max Power	25W
Net weight	1.5kg
